Cat pumps 67 Frame Plunger pump 6761

Cat pumps 67 Frame plunger pump 6761

The Cat Pumps 67 frame plunger pump 6761 is designed to meet the most demanding needs of industrial and commercial environments.

Specifications Cat Pumps 6761

With a maximum flow of 227 l/m and a pressure range of 6.8 to 83 bar, the Cat Pumps 6761 provides the reliability and performance you need for your high-pressure applications. The triplex plunger design ensures high efficiency and low pulsations. The special ported inlet manifold allows external flushing fluid, providing cooling at high temperatures and lubrication in low-lubricity fluids.

The Cat Pumps 6761's durable V-packings are fully lubricated and cooled by the pumped fluid, extending seal life and minimizing maintenance requirements. In addition, preset low-pressure seals provide secondary protection against external leaks, without the need for packaging adjustments.

With special high-quality, polished, concentric, ceramic plungers, this pump provides a wear surface and significantly extends the life of the seals. NBR seals are supplied as standard, but we also offer alternative options for temperature and chemical compatibility, such as FPM (.0110) and EPDM (.0220).

Personal advice about Cat Pumps

Do you have questions or would you like to know more about how this pump can meet your specific needs? Our dedicated customer service team is ready to assist you. Don't hesitate to contact us and we will be happy to help you.

Documents Cat Pumps 6761

Cat Pumps Datasheet 6761
