Cat Pumps 5CP Plunger Pump – 5CP4120CSS

Cat Pumps 5CP Plunger Pump – 5CP4120CSS
In stock

Material: Brass
Flow: 4.5 gpm / 17.0 lpm
Pressure: 100 to 4000 psi / 6.9 to 275 bar
Speed: 1750 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C Read more..

3-5 days
  • Large own stock

  • Outstanding service

  • Fast delivery (1-2 days)

  • Thé Cat Pumps-dealer since 1978

Product description

This is a Cat Pumps triplex plunger pump with a brass pump head with stainless steel valves and solid ceramic plungers. This pump is standard equipped with NBR seals and O-rings and is available in the variants below. The pump can be fitted with alternative seals, depending on the chemical composition of the medium to be pumped or the operating temperature.

TYPEDESCRIPTIONMAX. TEMP.SUFFIX
NBRMedium Nitrile (Buna-N) seals and O-Rings160°F (71°C)-
FPMFluorocarbon (Viton®) seals and O-Rings, chemical resistance180°F (82°C).0110
EPDMEthylene Propylene Diene Monomer seals and O-Rings160°F (71°C).0220
HTHigh-temperature high pressure seals180°F (88°C).3000
STHTHigh-temperature high pressure seals, special Teflon® low-pressure seals, NBR O-Rings190°F (88°C).3400
 High-temperature high pressure seals, special Teflon® low-pressure seals, FPM O-Rings190°F (88°C).3410
PTFEPure Polytetrafluoroethylene (Teflon®) Seals and Buna-N O-Rings190°F (88°C).0700
 Pure Polytetrafluoroethylene (Teflon®) Seals and FPM O-Rings200°F (93°C).0710
IPFEI-Perfluoroelastomer (Teflon®) Seals and Isolast O-Rings200°F (93°C).0770
ST4Special blend PTFE high and low pressure seals, Buna-N O-Rings190°F (88°C).4400
 Special blend PTFE high and low pressure seals, FPM O-Rings200°F (93°C).4410
NBRSBuna-N silicone free seals and O-Rings160°F (71°C).6000

FPM = Fluorocarbon, EPDM = Ethylene Propylene Diene Monomer, HT = High Temp (EPDM Alternative), STHT = Special PTFE High Temperature, PTFE = Pure Polytetrafluoroethylene, IPFE = I-Perfluoroelastomer, ST4 = Special PTFE 4, NBR = Medium Nitrile (Buna-N), NBRS = Buna-N silicon free seals and O-Rings.
Viton® and Teflon® are registered trademarks of DuPont Dow Elastomers.



Documents

Cat Pumps Datasheet - Models 5CP4110CSS, 5CP4112CSS, 5CP4114CSS, 5CP4116CSS, 5CP4118CSS, 5CP4120CSS - Pijttersen
Cat Pumps Service Manual - CP Plunger Pump - Pijttersen
Cat Pumps - Installation guidelines for high-pressure pumps - Pijttersen
Cat Pumps - Warnings and cautions for HP-pumps - Pijttersen

Specifications

Article number
5CP4120
SKU
5CP4120
Flow
4.5 gpm / 17 lpm
Pressure Range
Material Manifold
Brass
Speed
1750 rpm
Max. Liquid Temp. (NBR)
160°F / 71°C

Specifications

Article number
5CP4120
SKU
5CP4120
Flow
4.5 gpm / 17 lpm
Pressure Range
Material Manifold
Brass
Speed
1750 rpm
Max. Liquid Temp. (NBR)
160°F / 71°C

Cat Pumps 5CP Plunger Pump – 5CP4120CSS

0 reviews

Review Cat Pumps Cat Pumps 5CP Plunger Pump – 5CP4120CSS

Material: Brass
Flow: 4.5 gpm / 17.0 lpm
Pressure: 100 to 4000 psi / 6.9 to 275 bar
Speed: 1750 r..
