High pressure pumps

Cat Pumps 3 Frame Piston Pump - 280

3 Frame Piston Pump - 280

Material: Brass
Flow: 3.0 gpm / 11.4 lpm
Pressure: 100 – 1000 psi / 6.9 – 70 bar
Speed: 1330 rpm
Inlet Pressure Range: -8.5 to 40 psi / -0.6 to 2.8 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps Cat Pumps 3CP1241

Cat Pumps 3CP1241

Material: Stainless Steel
Flow: 3.6 gpm / 13.6 lpm
Pressure: 100 – 2000 psi / 6.9 – 138 bar
Speed: 1725rpm
Inlet Pressure Range: Flooded to 70 psi / Flooded to 4.8 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 3CP Plunger Pump – 3CP1221

3CP Plunger Pump – 3CP1221

Material: Stainless Steel
Flow: 4.2 gpm / 16 lpm
Pressure: 100 – 2000 psi / 6.9 – 138 bar
Speed: 1725rpm
Inlet Pressure Range: Flooded to 70 psi / Flooded to 4.8 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 3 Frame Plunger Pump - 277

3 Frame Plunger Pump - 277

Material: Nickel Aluminium Bronze
Max. Flow: 3.5 gpm / 13.2 lpm
Max. pressure: 1500 psi / 6.9 – 103 bar
Speed: 1420 rpm
Inlet Pressure Range: Flooded to 60 psi / 0.1 – 4.1 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps Cat Pumps 3545HS

Cat Pumps 3545HS

Material: Brass
Flow rate: 170 lpm
Pressure range: 6.9 – 69 bar
Speed: 765 rpm
Inlet pressure: -0.35 – 4.8 bar
Max. fluid temperature: 60°C
Log in for prices
Cat Pumps Cat Pumps 3560DEx

Cat Pumps 3560DEx

Model: Cat Pumps 3560DEx
Material: Stainless steel
Flow rate: 76 lpm
Pressure: 275 bar
Speed: 1160 rpm
Max. fluid temperature: 71°C
Log in for prices
Cat Pumps Cat pumps 60 Frame piston pumps 6040

Cat pumps 60 Frame piston pumps 6040

The Cat Pumps 6040 piston pump is designed for reliable performance in a variety of applications. With a flow rate of 152 l/m, a pressure range from 7 to 105 bar and a rotation speed of 500 RPM, this pump is suitable for industrial applications.
Log in for prices
Cat Pumps Cat Pumps Direct Drive 2SF10SEEL

Cat Pumps Direct Drive 2SF10SEEL

Pressure Range: 6.9 - 83 bar
RPM: 1725 rpm
Flow: 3,8 l/m
Max. Liquid Temperature (NBR): 71°C
Log in for prices
Cat Pumps 15 Frame Plunger Pump - 654

15 Frame Plunger Pump - 654

Material: Brass
Flow: 4.5 gpm / 17 lpm
Pressure: 100 – 4000 psi / 6.9 – 280 bar
Speed: 790 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 5CP Plunger Pump – 5CP6251

5CP Plunger Pump – 5CP6251

Material: Stainless Steel
Flow: 5.0 gpm / 19 lpm
Pressure: 100 – 2000 psi / 6.9 – 138 bar
Speed: 1725 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 5CP Plunger Pump – 5CP2140WF

5CP Plunger Pump – 5CP2140WF

Material: Brass
Flow: 4.0 gpm / 15 lpm
Pressure: 100 – 2500 psi / 6.9 – 172 bar
Speed: 1725 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 25 Frame Plunger Pump - 2510

25 Frame Plunger Pump - 2510

Material: Brass
Flow: 20 gpm / 76 lpm
Pressure: 100 – 2000 psi / 6.9 – 138 bar
Speed: 1450 rpm
Inlet Pressure Range: Flooded to 70 psi / Flooded to 4.8 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 3 Frame Plunger Pump - 241

3 Frame Plunger Pump - 241

Material: Stainless Steel
Flow: 3.6 gpm / 13.6 lpm
Pressure: 100 – 1200 psi / 6.9 – 82 bar
Speed: 1725 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 15 Frame Plunger Pump - 1057

15 Frame Plunger Pump - 1057

Material: Nickel Aluminum Bronze
Flow: 10 gpm / 38 lpm
Pressure: 100 – 2200 psi / 6.9 – 152 bar
Speed: 958 rpm
Inlet Pressure Range: -5 – 60 psi / -0.35 – 4.1 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 10 Frame Piston Pump - 1010

10 Frame Piston Pump - 1010

Material: Brass
Flow: 13.0 gpm / 49 lpm
Pressure: 100 – 700 psi / 6.9 – 50 bar
Speed: 900 rpm
Inlet Pressure Range: -8.5 to 40 psi / -0.6 to 2.8 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps Direct-Drive – 2SF13ES

Direct-Drive – 2SF13ES

Material: Brass
Flow: 3.4 gpm / 13 lpm
Pressure: up to 1886 psi / up to 130 bar
Speed: 2800 rpm
Inlet Pressure Range: 1.5 to 75.4 psi / 0.1 to 5.2 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 15 Frame Plunger Pump model 661D

15 Frame Plunger Pump model 661D

Material: Brass
Flow: 10.0 gpm / 38 lpm
Pressure: 100 – 3000 psi / 6.9 – 207 bar
Speed: 1429 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 5CP Plunger Pump – 5CP2110W

5CP Plunger Pump – 5CP2110W

Material: Brass
Flow: 8.7 lpm
Pressure: 6.9 – 175 bar
Speed: 1420 rpm
Inlet Pressure Range: FFlooded to 4,1 bar
Max. medium temp.: 71°C
Log in for prices
Cat Pumps 10 Frame Piston Pump - 821

10 Frame Piston Pump - 821

Material: Stainless Steel
Flow: 10.0 gpm / 38 lpm
Pressure: 100 – 1000 psi / 6.9 – 70 bar
Speed: 940 rpm
Inlet Pressure Range: -8.5 to 40 psi / -0.6 to 2.8 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps Cat Pumps 5CP3120

Cat Pumps 5CP3120

Material: Brass
Flow: 4.5 gpm / 17 lpm
Pressure: 100 – 3500 psi / 6.9 – 241 bar
Speed: 1645 rpm
Inlet Pressure Range: -2.5 to 60 psi / -.2 to 4 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 3CP Plunger Pump – 3CP1120G

3CP Plunger Pump – 3CP1120G

Material: Brass
Flow: 3.5 gpm / 13.2 lpm
Pressure: 100 – 2200 psi / 6.9 – 152 bar
Speed: 3600 rpm
Inlet Pressure Range: Flooded to 70 psi / Flooded to 4.8 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 5 Frame Plunger Pump – 300

5 Frame Plunger Pump – 300

Material: Brass
Flow: 10 lpm
Pressure: up to 150 bar
Speed: 1420 rpm
Inlet Pressure Range: 0.1 to 4 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 3 Frame Plunger Pump - 270

3 Frame Plunger Pump - 270

Material: Brass
Flow: 3.5 gpm / 13.2 lpm
Pressure: 100 – 1500 psi / 6.9 – 103 bar
Speed: 1420 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C
Log in for prices
Cat Pumps 3 Frame Plunger Pump - 231

3 Frame Plunger Pump - 231

Material: Stainless Steel
Flow: 2.3 gpm / 8.7 lpm
Pressure: 100–1500 psi / 6.9–103 bar
Speed: 1725 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C
Log in for prices

Cat Pumps Netherlands

We are Cat Pumps NL – your reliable partner for high-quality high-pressure pump solutions. We have a passion for our profession and have years of experience in high-pressure pump technology. We listen to your technical questions and come up with the right solution. We do this with great pleasure, but above all very quickly. Thanks to our large stock of high-pressure pumps, we can deliver any solution quickly from our own warehouse in Zuidbroek. We know better than anyone that you only have one goal in mind and that is to keep your high-pressure pump running. Let's do that together from now on!

The quality of Catpumps high-pressure pumps

Cat Pumps is the A brand in the field of high-pressure technology and supplies high-quality industrial piston and plunger pumps. These pumps run in thousands of applications around the world. The quality is reflected in, among other things, the over-sizing, which means that the load is lower and the pumps run smoothly for a long time. In addition, the maintenance costs and service intervals of these high-pressure pumps are low due to the long service life of seals and valves. Do you opt for a Cat Pump? Then you choose a pump with nine lives!

Selecting the right Cat Pumps high pressure pump

Selecting the right pump for your application requires careful preparation. It is important that you identify the following requirements in advance so that you choose a pump that meets your requirements.

Yield in liters per minute
Working pressure in bar
Inlet conditions
Temperature of the liquid to be pumped
Liquid composition, viscosity, salinity or chemical name.

Not sure which pump is suitable for your application? Feel free to contact us. We are happy to think along with you and come up with the right high-pressure pump for your organization.

Our customer service

In addition to our high-quality products, we also provide excellent customer service and technical support. Our team of professionals is ready to help you choose the right pump, answer your questions and provide tailor-made solutions for your specific needs. In short, if you are looking for reliable, efficient and durable high-pressure pumps, Catpumps is the right choice. Discover our extensive range and contact us today for more information.
